Baking Painted Gondola Working Platform ZLP630 ZLP800 Anti Rust

    Buy cheap Baking Painted Gondola Working Platform ZLP630 ZLP800 Anti Rust from wholesalers

    Buy cheap Baking Painted Gondola Working Platform ZLP630 ZLP800 Anti Rust from wholesalers
    • Buy cheap Baking Painted Gondola Working Platform ZLP630 ZLP800 Anti Rust from wholesalers
    • Buy cheap Baking Painted Gondola Working Platform ZLP630 ZLP800 Anti Rust from wholesalers

    Baking Painted Gondola Working Platform ZLP630 ZLP800 Anti Rust

    Ask Lasest Price
    Brand Name : Luwang
    Model Number : zlp800
    Certification : ISO9001 , CE
    Payment Terms : L/C, T/T
    Supply Ability : 1000sets/month
    Delivery Time : 10-25days
    • Product Details
    • Company Profile

    Baking Painted Gondola Working Platform ZLP630 ZLP800 Anti Rust

    ZLP630 ZLP800 ZLP1000 Window cleaning gondola Suspended Working Platform


    Rated load:800kg
    Lifting height: 50-200m
    Lifting speed: 8.2m/min
    Material: National standard Q235 steel/ Aluminum alloy
    Color: Customized
    Surface treatment: Paint/hot galvanized
    Platform Dimensiones(L×W×H):7.5m×0.69m×1.18m
    Thickness of steel structure : 2.0mm/2.2mm

    Suspension mechanism: Rated front beam overhang:1500mm
    Rated suspension mass: 8KN×2
    The width of the cantilever beam to the ground is 1200mm
    Maximum spacing of front and rear support is 4600mm
    Front beam(L×W×H): 2300mm×75mm×75mm 2300mm×80mm×80mm Thickness:4.5mm 4.0mm
    Middle beam(L×W×H): 2300mm×88mm×88mm 2300mm×70mm×70mm Thickness:3.5mm
    Rear beam(L×W×H): 2300mm×75mm×75mm 2300mm×80mm×80mm Thickness:3.5mm


    Certificates:
