    Aluminum Alloy Electric Suspended Platform Anti Rust High Load Capacity

    Ask Lasest Price
    Brand Name : luwang
    Model Number : zlp1000
    Certification : ISO9001 CE
    Supply Ability : 1000sets/month
    Delivery Time : 10-25days
    • Product Details
    • Company Profile

    Aluminum Alloy Electric Suspended Platform Anti Rust High Load Capacity


    Competitive Price Suspended Platform construction building facade cleaning


    PRODUCT DETAILS:


    Suspended platform gondolas are an easy-to-use and effecient solution for building maintenance and repair.


    Suspended platforms have taken over the role of scaffolding ladders. Suspended platforms are mechanical devices that lift workers into the air to complete work at hard to reach heights. It is widely used in exterior wall construction, cleaning, maintenance, painting, power station, ship yards, municipal projects, etc.


    PARAMETERS:


    Rated load:1000kg
    Lifting height: 50-200m
    Lifting speed: 8.2m/min
    Material: National standard Q235 steel/ Aluminum alloy
    Color: Customized
    Surface treatment: Paint/hot galvanized
    Platform Dimensiones(L×W×H):7.5m×0.69m×1.18m
    Thickness of steel structure : 2.0mm/2.2mm
    Suspension mechanism: Rated front beam overhang:1500mm
    Rated suspension mass: 8KN×2
    The width of the cantilever beam to the ground is 1200mm
    Maximum spacing of front and rear support is 4600mm
    Front beam(L×W×H): 2300mm×75mm×75mm 2300mm×80mm×80mm Thickness:4.5mm 4.0mm
    Middle beam(L×W×H): 2300mm×88mm×88mm 2300mm×70mm×70mm Thickness:3.5mm
    Rear beam(L×W×H): 2300mm×75mm×75mm 2300mm×80mm×80mm Thickness:3.5mm

    APPLICATION:

    Suspended platforms have taken over the role of scaffolding ladders. Suspended platforms are mechanical devices that lift workers into the air to complete work at hard to reach heights. It is widely used in exterior wall construction, cleaning, maintenance, painting, power station, ship yards, municipal projects, etc.


    ADVANTAGES:


    ZLP series electric baskets have passed the test of various complicated conditions with high-quality design concept and mature performance quality. Compared with similar products, they have the advantages of safety, economy, high efficiency and convenience.
